BOITIER GAMING MICRO-ATX GAMEMAX VISTA MB WHITE
oitier Gaming Micro-ATX GAMEMAX Vista WHITE
Vista MicroATX tower PC ATX case – Aesthetic looks, airflow focus, easy installation, and ample room for large GPU and cable management. Good build quality computer case made of heavy-duty steel metal frame and 4.0mm tempered glass. Computer Case Focus on Cooling- The modular motherboard I/O allows you to move the motherboard to a higher/lower position for air-cooled/water-cooled systems. To ensure adequate airflow, a Total 9x120mm fan position, Fine mesh panel at the top, and on the PSU shroud side, help with great ventilation. Easy Build Gaming PC Case- This case has a lot of flexibilities convenient for components installations: Removeable 5x Sides, Glass to Glass full view; Spacious PC case with Easy Cable Management, A seal plate on the top radiator bracket ensures no pressure leak when installing smaller than a 360 radiator/3x120mm fans at the top. Latest Gen. Large Graphics Card Ready- This Mid-tower Case is compatible with the largest NVIDIA 4000 series cards thanks to its ample room for graphics cards up to 410mm in length, and 165mm in height (for air cooling mode)
Boitier Gaming Micro-ATX GAMEMAX Vista MB Black fiche technique:
Brand: Gamemax
Model: Vista Black Category: Boitiers & Barbones
Vista MW Form Factor MICRO ATX
Chassis SPCC :0.6mm
PSU Form Factor Bottom/ATX
M/B Form Factor M-ATX(200mm)、ITX
Front Panel Tempered Glass,Mesh
Top Panel Metal cover
Side Panel Left Tempered Glass,Mesh
Right metal cover
External Drive
Bay(s) 5.25″ (ODD) *0
3.5″ *0
Internal Drive
Bay(s) 3.5″ (HDD) *2
2.5″ (SSD) *2
1*3.5HDD+2*2.5SSD or 2*3.5HDD+1*2.5SSD
I/O Buttons *3
USB2.0 Port(s) *2
USB3.0 Port(s) *1
Audio Support *1 (COMBO AUDIO)
Card Reader (Support) *0
RGB Controller *1(Optional)
Controller max. fans *0
RGB Controller max. LED strips *0
Remote (IR or RF) *1(Optional)
Cooling Fan
Support Front *0
Top 3x120mm ,2x140mm (Fan optional)
Rear 1x120mm (Fan optional)
M/B Cover 2x120mm (Fan optional)
PSU Cover 3x120mm (Reverse fan blade)(Fan optional)
Water Cooling Support
(Radiator Size) Front *0
Top 120mm, 140mm,240mm,280mm,360mm
Rear 120mm
M/B Cover 120mm, 240mm
Dust Cover Bottom, right side panel and top cover with dust filter
Slots *5
Dimensions Chassis (L)415*(W)210*(H)435mm
Full Case (inc Fascia) (L)433*(W)210*(H)450mm
Carton (L)517*(W)282*(H)496mm
VGA Card Length Up to 410mm
CPU Cooler Height 165mm
SPS Length up to 265mm
Cable Management Depth 25mm
oitier Gaming Micro-ATX GAMEMAX Vista WHITE
Vista MicroATX tower PC ATX case – Aesthetic looks, airflow focus, easy installation, and ample room for large GPU and cable management. Good build quality computer case made of heavy-duty steel metal frame and 4.0mm tempered glass. Computer Case Focus on Cooling- The modular motherboard I/O allows you to move the motherboard to a higher/lower position for air-cooled/water-cooled systems. To ensure adequate airflow, a Total 9x120mm fan position, Fine mesh panel at the top, and on the PSU shroud side, help with great ventilation. Easy Build Gaming PC Case- This case has a lot of flexibilities convenient for components installations: Removeable 5x Sides, Glass to Glass full view; Spacious PC case with Easy Cable Management, A seal plate on the top radiator bracket ensures no pressure leak when installing smaller than a 360 radiator/3x120mm fans at the top. Latest Gen. Large Graphics Card Ready- This Mid-tower Case is compatible with the largest NVIDIA 4000 series cards thanks to its ample room for graphics cards up to 410mm in length, and 165mm in height (for air cooling mode)
Boitier Gaming Micro-ATX GAMEMAX Vista MB Black fiche technique:
Brand: Gamemax
Model: Vista Black Category: Boitiers & Barbones
Vista MW Form Factor MICRO ATX
Chassis SPCC :0.6mm
PSU Form Factor Bottom/ATX
M/B Form Factor M-ATX(200mm)、ITX
Front Panel Tempered Glass,Mesh
Top Panel Metal cover
Side Panel Left Tempered Glass,Mesh
Right metal cover
External Drive
Bay(s) 5.25″ (ODD) *0
3.5″ *0
Internal Drive
Bay(s) 3.5″ (HDD) *2
2.5″ (SSD) *2
1*3.5HDD+2*2.5SSD or 2*3.5HDD+1*2.5SSD
I/O Buttons *3
USB2.0 Port(s) *2
USB3.0 Port(s) *1
Audio Support *1 (COMBO AUDIO)
Card Reader (Support) *0
RGB Controller *1(Optional)
Controller max. fans *0
RGB Controller max. LED strips *0
Remote (IR or RF) *1(Optional)
Cooling Fan
Support Front *0
Top 3x120mm ,2x140mm (Fan optional)
Rear 1x120mm (Fan optional)
M/B Cover 2x120mm (Fan optional)
PSU Cover 3x120mm (Reverse fan blade)(Fan optional)
Water Cooling Support
(Radiator Size) Front *0
Top 120mm, 140mm,240mm,280mm,360mm
Rear 120mm
M/B Cover 120mm, 240mm
Dust Cover Bottom, right side panel and top cover with dust filter
Slots *5
Dimensions Chassis (L)415*(W)210*(H)435mm
Full Case (inc Fascia) (L)433*(W)210*(H)450mm
Carton (L)517*(W)282*(H)496mm
VGA Card Length Up to 410mm
CPU Cooler Height 165mm
SPS Length up to 265mm
Cable Management Depth 25mm
