Maximum Operating Pressure (bar) :700
Cylinder Compatability: Single-acting, Double-Acting
Reservoir Capacity (cm3): 250000
Usable Oil Capacity (litres): 250
Maximum Flow at Rated Pressure: 2,1 l/min
Variable Output Flow Low Pressure Less Than 125 bar (l/Min): 3,3-11,1
Variable Output Flow High Pressure Greater Than 125 bar (l/Min): 0,6-2,1
Number of Outlets: 8
Motor Size (hp): 4
Motor Hertz: 50/60 Hz
Motor Phases: 3 Ph
Motor Voltage: 380-415 V
Duty Cycle: Extended
Valve Operation
Solenoid
Valve Type: 4-way, 3-position
Power Source: Electric
Motor Electrical Specification: 380-415 V, 3 Ph, 50-60 Hz
Number of Lift Points: 8
Accuracy Over Full Stroke: 1 mm
Weight (kg): 910
