CARTE MERE BATTLE-AX B760M-WHITE WIFI V20 LGA 1700 SOCKET DDR5
BATTLE-AX B760M-BLANC WIFI V20
• Carte mère blanche personnalisée exclusive pour la série Tomahawk
• Alimentation renforcée 12+1+1 phases
• Fournit 3 emplacements SSD PCIe 4.0 x4 M.2
• Fournit une interface arrière haute vitesse USB 3.2 Gen 2 Type-C et deux interfaces arrière USB 3.2 Gen 1 Type-A
• Équipé d'une carte réseau filaire haut débit Realtek 2.5G et d'une carte réseau sans fil AX101 WiFi 6, prenant en charge Bluetooth 5.2
• Prend en charge le logiciel de contrôle de l'efficacité lumineuse iGame Center, qui peut ajuster de manière synchrone l'efficacité lumineuse du radiateur, du ventilateur de refroidissement et de la mémoire
• Six technologies de protection, un fonctionnement plus stable du produit
• 200 processus sont rigoureusement testés avec une qualité garantie
• Le processus d'atomisation des PCB a été entièrement mis à niveau.
Model BATTLE-AX B760M-WHITE WIFI V20
Product Series BATTLE-AX series
Chipset Intel B760
Processor Support the 14th/13th and 12th generation Intel adapting to the LGA 1700 slot of the motherboard ® Core TM, Pentium ® And Cylon ® processor
(* Please visit for the latest memory compatibility list)
Memory 4 DDR4 memory sockets are provided, which can support up to 128 GB of memory (a single socket can support up to 32 GB of memory)
- Support DDR4-4800 (OC)/4600 (OC)/4400 (OC)/4266 (OC)/4000 (OC)/3733 (OC)/3600 (OC)/3466 (OC)/3200 (OC)/3000/2933/2800/2666/2400/2133MHz memory
- Support Extreme Memory Profile (XMP) memory technology
- Supports dual channel memory technology
(* Please visit for the latest memory compatibility list)
SATA Ports 3 M.2 slots and 4 SATA 6Gb/s hard disk interfaces, Support the creation of RAID 0, RAID 1, RAID 5, and RAID 10 disk arrays using SATA hard disk devices
- M.2_1 slot: supports 2242/2260/2280 M.2 SSD (PCIe 4.0 x4, CPU channel)
- M.2_2 slot: supports 2242/2260/2280 M.2 SSD (PCIe 4.0 x4, PCH channel)
- M.2_3 slot: supports 2242/2260/2280 M.2 SSD (PCIe 4.0 x4, PCH channel)
(* See the official BIOS user guide of Colorful for the steps to create a RAID disk array)
Board I/O Rear I/O :
-4×USB 2.0 interfaces
-2×USB 3.2 Gen 1 Type-A interfaces
-1×USB 3.2 Gen 2 Type-C interface
-1×DP 1.2 interface, supports up to 4K 60Hz resolution
-1×HDMI 2.0 interface, supports up to 4K 60Hz resolution
-1×2.5G network interface
-2×Wi-Fi 6 antenna interfaces
-3×Audio interfaces (audio input/audio output/microphone)
On board:
-1×CPU fan pin
-3×System fan pins
-1×Water cooling pump pin
-1×USB 2.0 pin expandable 2 USB 2.0 Type-A interfaces
-1×USB 3.2 Gen 1 pin expandable 2 USB 3.2 Gen 1 Type-A interfaces
-1×USB 3.2 Gen 1 Type-C slot can expand 1 USB 3.2 Gen 1 Type-C interface
-2×5V 3-pin ARGB pins
-2×12V 4-pin RGB pins
-1×Front audio pin
-1×Front panel pin
-1×Speaker pin
-1×Clear CMOS jumper
-1×COM port pin
-1×BIOS burner pin
-1×POST card pin
-1×ME write protection jumper
-1×RGB light effect control jumper
Expansion Slots 1×PCIe 5.0 x16 slot
1×PCIe 3.0 x4 slot
BIOS 128M UEFI, support multiple languages
Power Management Support S3/S4 wake-up, network S5 wake-up, support USB wake-up, support timing boot, call boot
Hardware Monitor CPU fan speed is controllable, system fan speed is controllable (Fan1 supports independent control, Fan2 and Fan3 share control), CPU temperature monitoring, system temperature monitoring, and each group of voltage monitoring
LAN RTL8125 2.5Gbit LAN, AX101 WiFi 6 wireless network card, Bluetooth 5.2
Audio Realtek ALC897 high fidelity decoding chip, Support up to5.1 channels
Configuration M-ATX
245mm x 245mm
•
