Model
MPE-7501-ACABW-3B
ATX Version
ATX 12V Ver. 3.1
PFC
Active PFC
Input Voltage
200-240V
Input Current
6A
Input Frequency
50-60Hz
Dimensions (L x W x H)
140 x 150 x 86 mm / 5.5 x 5.9 x 3.4 inch
Fan Size
120mm
Fan Bearing
HDB
Efficiency
>88% @ Typical Load
80 PLUS Rating
80 PLUS Bronze EU 230V
ErP 2014 Lot 3
Yes
Operating Temperature
0-40°C
Power Good Signal
100 - 150 ms
Hold Up Time
>16ms
MTBF
>100,000 Hours
Protections
UVP / OVP / OPP / OTP / SCP
Regulatory
TUV, CE, FCC, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (based on region's request.)
ATX 24 Pin Connectors
1
EPS 8 Pin / 4+4 Pin Connectors
2
SATA Connectors
6
Peripheral 4 Pin Connectors
3
PCI-e 6+2 Pin Connectors
4
Warranty
5 Years
Series
MWE Bronze Series
Category
500 to 750W
Modular
Non Modular
80 Plus Efficiency
Bronze
Form Factor
ATX
Watts
750W
MPE-7501-ACABW-3B
ATX Version
ATX 12V Ver. 3.1
PFC
Active PFC
Input Voltage
200-240V
Input Current
6A
Input Frequency
50-60Hz
Dimensions (L x W x H)
140 x 150 x 86 mm / 5.5 x 5.9 x 3.4 inch
Fan Size
120mm
Fan Bearing
HDB
Efficiency
>88% @ Typical Load
80 PLUS Rating
80 PLUS Bronze EU 230V
ErP 2014 Lot 3
Yes
Operating Temperature
0-40°C
Power Good Signal
100 - 150 ms
Hold Up Time
>16ms
MTBF
>100,000 Hours
Protections
UVP / OVP / OPP / OTP / SCP
Regulatory
TUV, CE, FCC, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (based on region's request.)
ATX 24 Pin Connectors
1
EPS 8 Pin / 4+4 Pin Connectors
2
SATA Connectors
6
Peripheral 4 Pin Connectors
3
PCI-e 6+2 Pin Connectors
4
Warranty
5 Years
Series
MWE Bronze Series
Category
500 to 750W
Modular
Non Modular
80 Plus Efficiency
Bronze
Form Factor
ATX
Watts
750W
