Cooler Specification
Socket compatibility AMD AM5, AM4 and Intel LGA1851, LGA1700, LGA1200, LGA1156, LGA1155, LGA1151, LGA1150
Height (without fan) 168 mm
Width (without fan) 150 mm
Depth (without fan) 127 mm
Weight (without fan) 1180 g
Height (with fan) 168 mm
Width (with fan) 150 mm
Depth (with fan) 152 mm
Weight (with fan) 1525 g
Material Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating
NSPR 228
Fan compatibility 140x150x25 (with 120mm mounting holes), 140x140x25 (with 120mm mounting holes), 120x120x25 (optional NA-SFC12 fan clips required)
Scope of delivery
2x NF-A14x25r G2 PWM premium fan
2x NA-RC16 Low-Noise Adaptor (L.N.A.)
NA-YC1 4-pin PWM splitter cable
NT-H2 high-grade thermal compound
NA-TPG1 thermal paste guard for AM5
NA-CW1 cleaning wipe
SecuFirm2+™ multi-socket mounting system
4x NM-ISW1 shim washers for LGA1700
NM-SD1 Torx® T20 screwdriver
Noctua metal case-badge
Warranty 6 years
FAN Specification
Model 2x NF-A14x25r G2 PWM
Bearing
SSO2
Max. rotational speed (+/- 10%) 1500 RPM
Max. rotational speed with L.N.A. (+/- 10%) 1250 RPM
Max. airflow 155.6 m³/h
Max. airflow with L.N.A. 127.1 m³/h
Max. acoustical noise 24.8 dB(A)
Max. acoustical noise with L.N.A. 19.7 dB(A)
Blade geometry Progressive-Bend impeller
Acoustical noise 24.8 dB(A)
Input power (max.) 2.28 W
Voltage range 12 V
MTTF > 150.000 h
Socket compatibility AMD AM5, AM4 and Intel LGA1851, LGA1700, LGA1200, LGA1156, LGA1155, LGA1151, LGA1150
Height (without fan) 168 mm
Width (without fan) 150 mm
Depth (without fan) 127 mm
Weight (without fan) 1180 g
Height (with fan) 168 mm
Width (with fan) 150 mm
Depth (with fan) 152 mm
Weight (with fan) 1525 g
Material Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating
NSPR 228
Fan compatibility 140x150x25 (with 120mm mounting holes), 140x140x25 (with 120mm mounting holes), 120x120x25 (optional NA-SFC12 fan clips required)
Scope of delivery
2x NF-A14x25r G2 PWM premium fan
2x NA-RC16 Low-Noise Adaptor (L.N.A.)
NA-YC1 4-pin PWM splitter cable
NT-H2 high-grade thermal compound
NA-TPG1 thermal paste guard for AM5
NA-CW1 cleaning wipe
SecuFirm2+™ multi-socket mounting system
4x NM-ISW1 shim washers for LGA1700
NM-SD1 Torx® T20 screwdriver
Noctua metal case-badge
Warranty 6 years
FAN Specification
Model 2x NF-A14x25r G2 PWM
Bearing
SSO2
Max. rotational speed (+/- 10%) 1500 RPM
Max. rotational speed with L.N.A. (+/- 10%) 1250 RPM
Max. airflow 155.6 m³/h
Max. airflow with L.N.A. 127.1 m³/h
Max. acoustical noise 24.8 dB(A)
Max. acoustical noise with L.N.A. 19.7 dB(A)
Blade geometry Progressive-Bend impeller
Acoustical noise 24.8 dB(A)
Input power (max.) 2.28 W
Voltage range 12 V
MTTF > 150.000 h
