Applicable fibers SM (ITU-T G.652), MM (ITU-T G.651), DS (ITU-T G.653), NZ/NZDS (ITU-T G.655), BI (ITU-T G.657)
Splice mode single fiber
Cladding diameter 80 - 150 µm
Coating diameter 100 - 1000 µm
Cleave length 8~16 mm
Average splice loss SM: 0.02 dB, MM: 0.01 dB, DS: 0.04 dB, NZ/NZDS: 0.04 dB, BI: 0.02 dB
Return loss ≥ 60 dB
Average splice time
6 sec. SM-SM Fast program
12 sec. AUTO program
Splice protector : 10-60 mm
Splice data storage : max. 3000
Fiber : magnification
300x for : X or Y single axis view
180x : for both X and Y dual-axis view
Display and camera : 2 cameras,
4.1-inch color screen
Electrode life 3500 arc discharges
Power supply / battery AC 100-240 V, 50/60 Hz
7800 mAh battery
Dimensions 135 (W) x 149 (H) x 156 (D) mm
Weight 2 kg (w/o battery)
Splice mode single fiber
Cladding diameter 80 - 150 µm
Coating diameter 100 - 1000 µm
Cleave length 8~16 mm
Average splice loss SM: 0.02 dB, MM: 0.01 dB, DS: 0.04 dB, NZ/NZDS: 0.04 dB, BI: 0.02 dB
Return loss ≥ 60 dB
Average splice time
6 sec. SM-SM Fast program
12 sec. AUTO program
Splice protector : 10-60 mm
Splice data storage : max. 3000
Fiber : magnification
300x for : X or Y single axis view
180x : for both X and Y dual-axis view
Display and camera : 2 cameras,
4.1-inch color screen
Electrode life 3500 arc discharges
Power supply / battery AC 100-240 V, 50/60 Hz
7800 mAh battery
Dimensions 135 (W) x 149 (H) x 156 (D) mm
Weight 2 kg (w/o battery)
